A solver for MPC-Dis(W)CSP4. More...

Inheritance diagram for frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable >:

[legend]

Public Member Functions
	MPC_DisWCSP4solver ()
	Constructor for MPC-DisWCSP4.
	MPC_DisWCSP4solver (String agentDescFile)
	Constructor from an agent configuration file.
	MPC_DisWCSP4solver (String agentDescFile, boolean useTCP)
	Constructor from an agent configuration file.
	MPC_DisWCSP4solver (Document agentDesc)
	Constructor.
	MPC_DisWCSP4solver (Document agentDesc, boolean useTCP)
	Constructor.
List< StatsReporter >	getSolGatherers ()
Solution< V, U >	buildSolution ()
Solution< V, U >	solve (Document problem, boolean measureMsgs, Long timeout, int infiniteCost, int maxTotalCost)
	Solves the input problem.
Public Member Functions inherited from frodo2.algorithms.AbstractDCOPsolver< V extends Addable< V >, U extends Addable< U >, S extends Solution< V, U >
	AbstractDCOPsolver (String agentDesc, boolean measureTime, boolean useTCP, boolean measureMsgs, Class<? extends XCSPparser< V, U > > parserClass, Class< V > domClass, Class< U > valuationClass)
	Constructor.
S	solve (Document problem, int nbrElectionRounds, boolean measureMsgs, Long timeout, boolean cleanAfterwards)
S	solve (DCOPProblemInterface< V, U > problem, int nbrElectionRounds, boolean measureMsgs, Long timeout, boolean cleanAfterwards)
S	solve (Document problem)
S	solve (DCOPProblemInterface< V, U > problem)
S	solve (Document problem, Long timeout)
S	solve (DCOPProblemInterface< V, U > problem, Long timeout)
S	solve (Document problem, boolean cleanAfterwards)
S	solve (DCOPProblemInterface< V, U > problem, boolean cleanAfterwards)
S	solve (Document problem, int nbrElectionRounds)
S	solve (DCOPProblemInterface< V, U > problem, int nbrElectionRounds)
S	solve (Document problem, int nbrElectionRounds, boolean measureMsgs)
S	solve (DCOPProblemInterface< V, U > problem, int nbrElectionRounds, boolean measureMsgs)
S	solve (Document problem, int nbrElectionRounds, boolean measureMsgs, Long timeout)
S	solve (DCOPProblemInterface< V, U > problem, int nbrElectionRounds, boolean measureMsgs, Long timeout)
S	solve (Document problem, int nbrElectionRounds, Long timeout)
S	solve (DCOPProblemInterface< V, U > problem, int nbrElectionRounds, Long timeout)
S	solve (Document problem, boolean cleanAfterwards, Long timeout)
S	solve (DCOPProblemInterface< V, U > problem, boolean cleanAfterwards, Long timeout) throws OutOfMemoryError
Public Member Functions inherited from frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >
void	setProblem (P problem)
	Sets the problem.
void	setFactory (AgentFactory< V, U > factory)
	Sets the agent factory.
void	setDomClass (Class< V > domClass)
	Sets the class for variable values.
void	setUtilClass (Class< U > utilClass)
	Sets the class for utility values.
Document	getAgentDesc ()
abstract List<? extends StatsReporter >	getSolGatherers ()
abstract S	buildSolution ()
S	solve (Document problem)
	Solves the input problem.
String	plotStats (Solution< V, U > sol)
	Puts the statistics in a format that can easily be processed after the experiments.
String	plotDummyStats (boolean maximize)
	Used when the solver was not able to solve the problem.

Private Member Functions
void	setMaxCost (int infiniteCost, int maxTotalCost)
	Sets the maximum total cost of any solution.

Private Attributes
SolutionCollector< V, U >	solCollector
	The module that gathers solution statistics.

Additional Inherited Members
Static Public Member Functions inherited from frodo2.algorithms.AbstractDCOPsolver< V extends Addable< V >, U extends Addable< U >, S extends Solution< V, U >
static void	main (String[] args) throws Exception
	Solves a problem and writes statistics to a file.
Protected Member Functions inherited from frodo2.algorithms.AbstractDCOPsolver< V extends Addable< V >, U extends Addable< U >, S extends Solution< V, U >
String	getFileHeader (Document problemFile)
	Returns the header for the output CSV file.
String	getParamsHeader ()
String	getParamsToLine ()
String	getProbStats (Document problemFile, String probFilename)
	Parses the statistics about the problem instance.
String	getTimeoutLine (String algoName, Document problemFile, String probFilename)
	Returns a timeout line for the output CSV file.
	AbstractDCOPsolver ()
	Dummy constructor.
	AbstractDCOPsolver (String agentDescFile)
	Constructor from an agent configuration file.
	AbstractDCOPsolver (String agentDescFile, boolean useTCP)
	Constructor from an agent configuration file.
	AbstractDCOPsolver (String agentDescFile, boolean useTCP, int shift)
	Constructor from an agent configuration file.
	AbstractDCOPsolver (Document agentDesc)
	Constructor.
void	parseParams (String[] params)
	Parses solver parameters.
	AbstractDCOPsolver (Document agentDesc, boolean useTCP)
	Constructor.
	AbstractDCOPsolver (Document agentDesc, Class< ? extends XCSPparser< V, U > > parserClass)
	Constructor.
	AbstractDCOPsolver (Document agentDesc, Class< ? extends XCSPparser< V, U > > parserClass, boolean useTCP)
	Constructor.
void	setNbrElectionRounds (int nbrElectionRounds)
	Sets the number of rounds of VariableElection.
void	setProblemRescalerShift (int shift)
	Sets the shift parameter of the ProblemRescaler module (if used).
void	overrideMsgTypes ()
	Overrides message types if necessary.
Protected Member Functions inherited from frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >
	AbstractSolver ()
	Dummy constructor.
void	clear ()
	Clears the parser.
Protected Attributes inherited from frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >
Document	agentDesc
	Description of the agent to be used.
AgentFactory< V, U >	factory
	The agent factory.
Class< ? extends XCSPparser< V, U > >	parserClass
	The class of the parser to be used.
List<? extends StatsReporter >	solGatherers
	The list of modules that record statistics about problem solving.
P	problem
	The problem.
final boolean	useTCP
	Whether to use TCP pipes or shared memory pipes.

Detailed Description

A solver for MPC-Dis(W)CSP4.

MPC-DisWCSP4 is the MPC-DisCSP4, with the weak extension to DisWCSPs initially proposed for MPC-DisCSP2 in the following paper:

Marius-Calin Silaghi and Debasis Mitra. Distributed constraint satisfaction and optimization with privacy enforcement. In Proceedings of the 2004 IEEE/WIC/ACM International Conference on Intelligent Agent Technology (IAT'04), pages 531-535, Beijing, China, September 20-24 2004. IEEE Computer Society Press.

MPC-DisCSP4 is described in the following paper:

Marius-Calin Silaghi. Hiding absence of solution for a distributed constraint satisfaction problem (poster). In Proceedings of the Eighteenth International Florida Artificial Intelligence Research Society Conference (FLAIRS'05), pages 854-855, Clearwater Beach, FL, USA, May 15-17 2005. AAAI Press.

Author: Thomas Leaute

Parameters

<V>	the type used for variable values
<U>	the type used for utility values

Constructor & Destructor Documentation

◆ MPC_DisWCSP4solver() [1/5]

frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable >.MPC_DisWCSP4solver ( )

Constructor for MPC-DisWCSP4.

◆ MPC_DisWCSP4solver() [2/5]

frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable >.MPC_DisWCSP4solver ( String agentDescFile )

Constructor from an agent configuration file.

Parameters

agentDescFile the agent configuration file (either for MPC-DisCSP4 or MPC-DisWCSP4)

◆ MPC_DisWCSP4solver() [3/5]

frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable< U > >.MPC_DisWCSP4solver	(	String	agentDescFile,
		boolean	useTCP )

Constructor from an agent configuration file.

Parameters

agentDescFile	the agent configuration file (either for MPC-DisCSP4 or MPC-DisWCSP4)
useTCP	whether to use TCP pipes or shared memory pipes

Warning: Using TCP pipes automatically disables simulated time.

References frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >.useTCP.

◆ MPC_DisWCSP4solver() [4/5]

frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable >.MPC_DisWCSP4solver ( Document agentDesc )

Constructor.

Parameters

agentDesc the agent configuration file

References frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >.agentDesc.

◆ MPC_DisWCSP4solver() [5/5]

frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable< U > >.MPC_DisWCSP4solver	(	Document	agentDesc,
		boolean	useTCP )

Constructor.

Parameters

agentDesc	the agent configuration file
useTCP	Whether to use TCP pipes or shared memory pipes

Warning: Using TCP pipes automatically disables simulated time.

References frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >.agentDesc, and frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >.useTCP.

Member Function Documentation

◆ buildSolution()

Solution< V, U > frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable >.buildSolution ( )

See also: AbstractDCOPsolver.buildSolution()

References frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >.factory, frodo2.algorithms.SolutionCollector< V extends Addable< V >, U extends Addable >.getSolution(), frodo2.algorithms.SolutionCollector< V extends Addable< V >, U extends Addable >.getUtility(), and frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >.problem.

Here is the call graph for this function:

◆ getSolGatherers()

List< StatsReporter > frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable >.getSolGatherers ( )

See also: AbstractDCOPsolver.getSolGatherers()

References frodo2.algorithms.SolutionCollector< V extends Addable< V >, U extends Addable >.setSilent().

Here is the call graph for this function:

◆ setMaxCost()

void frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable< U > >.setMaxCost	(	int	infiniteCost,
		int	maxTotalCost )

private

Sets the maximum total cost of any solution.

Parameters

infiniteCost	private constraints are only allowed to be soft constraints; infeasibility is identified by a cost of infiniteCost
maxTotalCost	maximum total cost of any solution; should be greater than (infiniteCost * number of agents) to guarantee correctness

Referenced by solve().

◆ solve()

Solution< V, U > frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable< U > >.solve	(	Document	problem,
		boolean	measureMsgs,
		Long	timeout,
		int	infiniteCost,
		int	maxTotalCost )

Solves the input problem.

Parameters

problem	the problem
measureMsgs	whether message sizes should be measured
timeout	timeout in ms, if `null`, no timeout is used
infiniteCost	private constraints are only allowed to be soft constraints; infeasibility is identified by a cost of infiniteCost
maxTotalCost	maximum total cost of any solution; should be greater than (infiniteCost * number of agents) to guarantee correctness

Returns: an optimal solution

References frodo2.algorithms.AbstractSolver< DCOPProblemInterface< V, U >, V, U, S >.problem, setMaxCost(), and frodo2.timeout.

Referenced by frodo2.algorithms.mpc_discsp.tests.MPC_DisWCSP4tests.test().

Here is the call graph for this function:

Member Data Documentation

◆ solCollector

SolutionCollector<V, U> frodo2.algorithms.mpc_discsp.MPC_DisWCSP4solver< V extends Addable< V >, U extends Addable >.solCollector

private

The module that gathers solution statistics.

The documentation for this class was generated from the following file:

src/frodo2/algorithms/mpc_discsp/MPC_DisWCSP4solver.java
