A UTIL propagation phase that maximizes worst-case utility with respect to the random variables. More...

Inheritance diagram for frodo2.algorithms.dpop.stochastic.robust.WorstCaseUTIL< Val extends Addable< Val >, U extends Addable >:

[legend]

Public Member Functions
	WorstCaseUTIL (Element parameters, DCOPProblemInterface< Val, U > problem)
	The constructor called in "statistics gatherer" mode.
	WorstCaseUTIL (DCOPProblemInterface< Val, U > problem, Element parameters)
	Constructor.
Public Member Functions inherited from frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable< U > >
	ExpectedUTIL (DCOPProblemInterface< Val, U > problem, Element parameters)
	Constructor.
	ExpectedUTIL (Element parameters, DCOPProblemInterface< Val, U > problem)
	The constructor called in "statistics gatherer" mode.
void	reset ()
Collection< MessageType >	getMsgTypes ()
void	getStatsFromQueue (Queue queue)
U	getWorstUtil ()
U	getExpectedUtil ()
U	getProbOfOptimality ()
void	notifyIn (Message msg)
HashMap< String, Val >	getSolution ()
Public Member Functions inherited from frodo2.algorithms.dpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >
MessageType	getStartMsgType ()
MessageType	getDFSMsgType ()
	UTILpropagation ()
	Default constructor.
	UTILpropagation (DCOPProblemInterface< Val, U > problem)
	Constructor.
	UTILpropagation (DCOPProblemInterface< Val, U > problem, Element parameters)
	Constructor from XML descriptions.
	UTILpropagation (Element parameters, DCOPProblemInterface< Val, U > problem)
	The constructor called in "statistics gatherer" mode.
void	setQueue (Queue queue)
void	setSilent (boolean silent)
Integer	getMaxMsgDim ()
U	getOptUtil ()
long	getFinalTime ()
	Returns the time at which this module has finished, determined by looking at the timestamp of the stat messages.
Public Member Functions inherited from frodo2.communication.IncomingMsgPolicyInterface< T >
default void	notifyIn (Message msg, Object toAgent)
	Notifies the listener of an incoming message.

Protected Member Functions
void	parseMethod (Element parameters)
ProjOutput< Val, U >	project (UtilitySolutionSpace< Val, U > space, String[] vars)
void	sendToParent (String var, String parentVar, String parentAgent, UtilitySolutionSpace< Val, U > space)
void	sendOutput (UtilitySolutionSpace< Val, U > space, String root)
Protected Member Functions inherited from frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable< U > >
void	sendSeparator (String sender, String senderAgent, String dest, String[] separator)
Protected Member Functions inherited from frodo2.algorithms.dpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >
void	init ()
	Parses the problem.
ClusterInfo	newClusterInfo ()
void	record (String senderVar, UtilitySolutionSpace< Val, U > space, ClusterInfo info)
	Records the input space until spaces from all children have been received.
void	projectAndSend (ClusterInfo info)
	Projects out a variable and sends the result to its parent (if any) or to itself (to initiate VALUE propagation).

Additional Inherited Members
Static Public Attributes inherited from frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable< U > >
static MessageType	RAND_VARS_PROJ_MSG_TYPE = SamplingPhase.RAND_VARS_PROJ_MSG_TYPE
	The type of the messages containing information about the where random variables should be projected out.
Static Public Attributes inherited from frodo2.algorithms.dpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >
static MessageType	START_MSG_TYPE = AgentInterface.START_AGENT
	The type of the message telling the module to start.
static MessageType	FINISH_MSG_TYPE = AgentInterface.AGENT_FINISHED
	The type of the message telling the agent finished.
static MessageType	DFS_MSG_TYPE = DFSgeneration.OUTPUT_MSG_TYPE
	The type of the messages containing information about the DFS.
static final MessageType	UTIL_MSG_TYPE = new MessageType ("DPOP", "UTILpropagation", "UTIL")
	The type of the messages containing utilities.
static final MessageType	OUTPUT_MSG_TYPE = new MessageType ("DPOP", "UTILpropagation", "UTILoutput")
	The type of the messages containing conditional optimal assignments.
static final MessageType	SEPARATOR_MSG_TYPE = new MessageType ("DPOP", "UTILpropagation", "Separator")
	The type of the messages containing separators.
static final MessageType	OPT_UTIL_MSG_TYPE = new MessageType ("DPOP", "UTILpropagation", "OptUtil")
	The type of the messages containing optimal utility values sent by roots.
static final MessageType	UTIL_STATS_MSG_TYPE = new MessageType ("DPOP", "UTILpropagation", "UTILstats")
	The type of messages sent to the statistics monitor.
Protected Attributes inherited from frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable< U > >
HashMap< String, HashSet< String > >	randVarsProj = new HashMap< String, HashSet<String> > ()
	For each variable, the random variables that should be projected out of its UTIL message.
Method	method = Method.EXPECTATION
	The method to use.
Protected Attributes inherited from frodo2.algorithms.dpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >
boolean	withAnonymVars = false
	Whether the parser should consider variables with no specified owner.
DCOPProblemInterface< Val, U >	problem
	The problem.
boolean	started = false
	Whether the execution of the algorithm has been started.
boolean	maximize = true
	`true` if we want to maximize utility, `false` if we want to minimize cost
Queue	queue
	The queue on which it should call sendMessage().
Map< String, ClusterInfo >	infos
	For each variable this agent owns, its relevant information.
String	myID
	This agent's name.
U	optUtil
	The optimal utility found to the problem.
boolean	reportStats = true
	Whether to report stats.

Detailed Description

A UTIL propagation phase that maximizes worst-case utility with respect to the random variables.

Author: Thomas Leaute

Parameters

<Val>	the type used for variable values
<U>	the type used for utility values

Constructor & Destructor Documentation

◆ WorstCaseUTIL() [1/2]

frodo2.algorithms.dpop.stochastic.robust.WorstCaseUTIL< Val extends Addable< Val >, U extends Addable< U > >.WorstCaseUTIL	(	Element	parameters,
		DCOPProblemInterface< Val, U >	problem )

The constructor called in "statistics gatherer" mode.

Parameters

problem	the overall problem
parameters	the description of what statistics should be reported

References frodo2.algorithms.dpop.UTILpropagation< Val extends Addable< Val >, U extends Addable >.problem.

◆ WorstCaseUTIL() [2/2]

frodo2.algorithms.dpop.stochastic.robust.WorstCaseUTIL< Val extends Addable< Val >, U extends Addable< U > >.WorstCaseUTIL	(	DCOPProblemInterface< Val, U >	problem,
		Element	parameters )

Constructor.

Parameters

problem	the agent's subproblem
parameters	the parameters for the module

References frodo2.algorithms.dpop.UTILpropagation< Val extends Addable< Val >, U extends Addable >.problem.

Member Function Documentation

◆ parseMethod()

void frodo2.algorithms.dpop.stochastic.robust.WorstCaseUTIL< Val extends Addable< Val >, U extends Addable >.parseMethod ( Element parameters )

protected

See also: ExpectedUTIL.parseMethod(Element)

Reimplemented from frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable >.

◆ project()

ProjOutput< Val, U > frodo2.algorithms.dpop.stochastic.robust.WorstCaseUTIL< Val extends Addable< Val >, U extends Addable< U > >.project	(	UtilitySolutionSpace< Val, U >	space,
		String[]	vars )

protected

See also: ExpectedUTIL#project(UtilitySolutionSpace, String[])

Todo: Add support for clusters

Todo: Implement an argProject() method

Reimplemented from frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable >.

Here is the call graph for this function:

◆ sendOutput()

void frodo2.algorithms.dpop.stochastic.robust.WorstCaseUTIL< Val extends Addable< Val >, U extends Addable< U > >.sendOutput	(	UtilitySolutionSpace< Val, U >	space,
		String	root )

protected

See also: ExpectedUTIL.sendOutput(UtilitySolutionSpace, java.lang.String)

Reimplemented from frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable >.

References frodo2.solutionSpaces.UtilitySolutionSpace< V extends Addable< V >, U extends Addable >.blindProject(), and frodo2.algorithms.dpop.UTILpropagation< Val extends Addable< Val >, U extends Addable >.problem.

Here is the call graph for this function:

◆ sendToParent()

void frodo2.algorithms.dpop.stochastic.robust.WorstCaseUTIL< Val extends Addable< Val >, U extends Addable< U > >.sendToParent	(	String	var,
		String	parentVar,
		String	parentAgent,
		UtilitySolutionSpace< Val, U >	space )

protected

See also: ExpectedUTIL#sendToParent(String, String, String, UtilitySolutionSpace)

Reimplemented from frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable >.

References frodo2.solutionSpaces.UtilitySolutionSpace< V extends Addable< V >, U extends Addable >.blindProject(), and frodo2.algorithms.dpop.stochastic.ExpectedUTIL< Val extends Addable< Val >, U extends Addable >.randVarsProj.

Here is the call graph for this function:

The documentation for this class was generated from the following file:

src/frodo2/algorithms/dpop/stochastic/robust/WorstCaseUTIL.java
