frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > > Class Template Reference

The UTIL propagation phase for O-DPOP. More...

Inheritance diagram for frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >:

Public Member Functions
	UTILpropagation (Element parameters, DCOPProblemInterface< Val, U > problem)
	Constructor for the statsreporter.
	UTILpropagation (DCOPProblemInterface< Val, U > problem, Element parameters)
	Constructor.
	UTILpropagation (DCOPProblemInterface< Val, U > problem)
	Alternative constructor not using XML.
void	notifyIn (Message msg)
	The algorithm.
VariableInfo	newVariableInfoInstanceInnerNode (String var, List< String > children, String parent, Val[] ownVariableDomain, List< UtilitySolutionSpace< Val, U > > usedSpaces, int numberOfChildren, U zeroUtility)
VariableInfo	newVariableInfoInstanceLeafNode (String var, List< String > children, String parent, Val[] ownVariableDomain, List< UtilitySolutionSpace< Val, U > > usedSpaces, int numberOfChildren, U zeroUtility)
void	startProcess (VariableInfo variable, int varIndex)
	This method starts the algorithm for the specified variable, i.e.
void	processDONE (VariableInfo variable, String sender)
	Method sets the entry for the corresponding agent of the done array in variable to true.
Public Member Functions inherited from frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >
	UTILpropagationFullDomain (Element parameters, DCOPProblemInterface< Val, U > problem)
	Constructor for the statsreporter.
void	getStatsFromQueue (Queue queue)
U	getOptUtil ()
long	getFinalTime ()
	Returns the time at which this module has finished, determined by looking at the timestamp of the stat messages.
void	setSilent (boolean silent)
Integer	getMaxMsgDim ()
Collection< MessageType >	getMsgTypes ()
void	notifyIn (Message msg)
	The algorithm.
VariableInfo	newVariableInfoInstanceInnerNode (String var, List< String > children, String parent, Val[] ownVariableDomain, List< UtilitySolutionSpace< Val, U > > usedSpaces, int numberOfChildren, U zeroUtility)
	Method to be used when var is an innernode.
VariableInfo	newVariableInfoInstanceLeafNode (String var, List< String > children, String parent, Val[] ownVariableDomain, List< UtilitySolutionSpace< Val, U > > usedSpaces, int numberOfChildren, U zeroUtility)
	Method to be used when var is an leafnode.
void	setQueue (Queue queue)
void	startProcess (VariableInfo variable, int varIndex)
	This method starts the algorithm for the specified variable, i.e.
void	reset ()

Protected Member Functions
LeafNode< U >	leafNodeInstance ()
void	utilPropagationFinished (String variableID, GoodsTree< Val, U, LeafNode< U > > tree, U utility, int domainSize)
void	processASK (VariableInfo variable)
	Method to process the ASK messages received by this agent.
Protected Member Functions inherited from frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >
L	leafNodeInstance ()
void	init ()
	Method used to initialize the agents fields.
void	processGOOD (VariableInfo variable, Good< Val, U > g, String sender, HashMap< String, Val[]> domains)
	Method used to process the GOOD messages received by this agent.
void	processASK (VariableInfo variable)
	Method to process the ASK messages received by this agent.
void	processDONE (VariableInfo variable, String sender)
	Method sets the entry for the corresponding agent of the done array in variable to true.
void	sendMessageToVariable (String receiver, Message msg, String variableID)
	Send a message to a variable.
void	log (String variableID, String message)
	Log function used to print the variables state during debugging.
void	utilPropagationFinished (String variableID, GoodsTree< Val, U, L > tree, U utility, int inducedWidth)
	Method called when util propagation phase for a certain variable has finished.

Private Member Functions
void	processGOOD (VariableInfo variable, Good< Val, U > g, String sender, int[] domInfo, String[] variables)
	Method used to process the GOOD messages received by this agent.

Additional Inherited Members
Static Public Attributes inherited from frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >
static MessageType	START_MSG_TYPE
	The type of the message telling the module to start.
static final MessageType	UTIL_MSG
	The type of the UTIL message.
static final MessageType	UTIL_MSG_VARS
	The type of a UTIL message with variables.
static final MessageType	UTIL_MSG_DOM
	The type of the UTIL message with domain information.
static final MessageType	UTIL_MSG_DOM_VARS
	The type of the UTIL message with domain information.
static final MessageType	ASK_MSG
	The type of the ASK message.
static final MessageType	DONE_MSG
	The type of the DONE message.
static final MessageType	OPT_UTIL_MSG_TYPE
	The type of the messages containing optimal utility values sent by roots.
static final MessageType	VALUE_PROP_START_MSG_TYPE
	The type of the message used to start the value propagation.
static final MessageType	GOODS_TREE_MSG_TYPE
	The type of the message used to send the GoodsTree to the VALUE propagation module.
static final MessageType	UTIL_STATS_MSG_TYPE
	The type of messages sent to the statistics monitor.
Protected Attributes inherited from frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >
boolean	reportStats
	Whether to report stats.
U	optTotalUtil
	The optimal, total utility reported to the stats gatherer.
Queue	queue
	The queue through which all communication flows.
DCOPProblemInterface< Val, U >	problem
	The agent's problem.
HashMap< String, Integer >	variablePointer
	Gives the variables' indexes in the arrays.
VariableInfo[]	infos
	The VariableInfo for each variable.
boolean[]	ready
	Tells one when a variable is ready to start the algorithm.
Map< String, String >	owners
	For each variable the agent that owns it.
boolean	started
	Whether the algorithm has been started.
boolean[]	receivedASK
	For each variable it stores whether an ASK message has been received.
HashMap< String, BufferedWriter >	loggers
	A list of buffered writers used to log information during debugging.
U	infeasibleUtil
	The minus infinty object.
boolean	agentFinished
	true when the agent has finished, and false otherwise
Integer	maxMsgDim
	In stats gatherer mode, the maximum number of variables in a UTIL message.
long	finalTime
	The time at which all UTIL propagation modules are finished.
boolean	maximize
	true when solving a maximization problem, and false otherwise
boolean	collectStats
	true when statistics should be collected in the tree, and false otherwise
Static Protected Attributes inherited from frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >
static final boolean	LOG
	To log or not to log.

Detailed Description

The UTIL propagation phase for O-DPOP.

Author

brammert

Parameters

<Val>	type used for variable values
<U>	type used for utility values

Todo

make it work for minimisation problems as well!

Constructor & Destructor Documentation

UTILpropagation() [1/3]

frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.UTILpropagation	(	Element	parameters,
		DCOPProblemInterface< Val, U >	problem )

Constructor for the statsreporter.

Parameters

problem	the overall problem
parameters	the description of what statistics should be reported (currently unused)

References frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.problem.

UTILpropagation() [2/3]

frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.UTILpropagation	(	DCOPProblemInterface< Val, U >	problem,
		Element	parameters )

Constructor.

Parameters

problem	The problem description
parameters	The parameters

References frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.problem.

UTILpropagation() [3/3]

frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.UTILpropagation

(

DCOPProblemInterface< Val, U >

problem

)

Alternative constructor not using XML.

Parameters

problem

The problem description

References frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.problem.

Member Function Documentation

leafNodeInstance()

LeafNode< U > frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.leafNodeInstance ( )

protected

Author

Brammert Ottens, 10 feb. 2011

Returns

a new instance of a leafnode

Referenced by newVariableInfoInstanceInnerNode().

newVariableInfoInstanceInnerNode()

VariableInfo frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.newVariableInfoInstanceInnerNode	(	String	var,
		List< String >	children,
		String	parent,
		Val[]	ownVariableDomain,
		List< UtilitySolutionSpace< Val, U > >	usedSpaces,
		int	numberOfChildren,
		U	zeroUtility )

See also

frodo2.algorithms.odpop.UTILpropagationFullDomain.newVariableInfoInstanceInnerNode(java.lang.String, java.util.List, java.lang.String, Addable[], java.util.List, int, frodo2.solutionSpaces.Addable)

References frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.collectStats, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.infeasibleUtil, leafNodeInstance(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.maximize, and frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.problem.

Here is the call graph for this function:

newVariableInfoInstanceLeafNode()

VariableInfo frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.newVariableInfoInstanceLeafNode	(	String	var,
		List< String >	children,
		String	parent,
		Val[]	ownVariableDomain,
		List< UtilitySolutionSpace< Val, U > >	usedSpaces,
		int	numberOfChildren,
		U	zeroUtility )

See also

frodo2.algorithms.odpop.UTILpropagationFullDomain.newVariableInfoInstanceLeafNode(java.lang.String, java.util.List, java.lang.String, Addable[], java.util.List, int, frodo2.solutionSpaces.Addable)

References frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.collectStats, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.infeasibleUtil, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.maximize, and frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.problem.

notifyIn()

void frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.notifyIn

(

Message

msg

)

The algorithm.

See also

StatsReporter.notifyIn(Message)

References frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.agentFinished, frodo2.communication.MessageType.equals(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.finalTime, notifyIn(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.OPT_UTIL_MSG_TYPE, and frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.queue.

Referenced by notifyIn().

Here is the call graph for this function:

processASK()

void frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.processASK ( VariableInfo variable )

protected

Method to process the ASK messages received by this agent.

Parameters

variable

The variable information

References frodo2.algorithms.odpop.Good< Val extends Addable< Val >, U extends Addable< U > >.getUtility(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.LOG, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.log(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.queue, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.reportStats, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.sendMessageToVariable(), and frodo2.algorithms.AgentInterface< V extends Addable< V > >.STATS_MONITOR.

Referenced by processDONE(), and startProcess().

Here is the call graph for this function:

processDONE()

void frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.processDONE	(	VariableInfo	variable,
		String	sender )

Method sets the entry for the corresponding agent of the done array in variable to true.

Parameters

variable	The variables to whom this message has been sent
sender	The sender of the message

References frodo2.algorithms.odpop.Good< Val extends Addable< Val >, U extends Addable< U > >.getUtility(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.LOG, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.log(), processASK(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.queue, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.reportStats, and frodo2.algorithms.AgentInterface< V extends Addable< V > >.STATS_MONITOR.

Here is the call graph for this function:

processGOOD()

void frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.processGOOD ( VariableInfo variable, Good< Val, U > g, String sender, int[] domInfo, String[] variables )

private

Method used to process the GOOD messages received by this agent.

Parameters

variable	The variable information
g	The good received
sender	The sender of the good
domInfo	domain size info reported by the child
variables	the variables for which domain size info is reported

References frodo2.algorithms.odpop.Good< Val extends Addable< Val >, U extends Addable< U > >.getUtility(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.LOG, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.log(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.queue, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.reportStats, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.sendMessageToVariable(), and frodo2.algorithms.AgentInterface< V extends Addable< V > >.STATS_MONITOR.

Here is the call graph for this function:

startProcess()

void frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.startProcess	(	VariableInfo	variable,
		int	varIndex )

This method starts the algorithm for the specified variable, i.e.

if the variable is the root an ASK message is sent. If not an ASK message is sent if an ASK message has been received

Parameters

variable	The variable info
varIndex	The index of the variable

References frodo2.algorithms.odpop.Good< Val extends Addable< Val >, U extends Addable< U > >.getUtility(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.LOG, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.log(), processASK(), frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.receivedASK, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.sendMessageToVariable(), frodo2.algorithms.odpop.Good< Val extends Addable< Val >, U extends Addable< U > >.toString(), and utilPropagationFinished().

Here is the call graph for this function:

utilPropagationFinished()

void frodo2.algorithms.odpop.UTILpropagation< Val extends Addable< Val >, U extends Addable< U > >.utilPropagationFinished ( String variableID, GoodsTree< Val, U, LeafNode< U > > tree, U utility, int domainSize )

protected

See also

frodo2.algorithms.odpop.UTILpropagationFullDomain.utilPropagationFinished(java.lang.String, frodo2.algorithms.odpop.goodsTree.GoodsTree, frodo2.solutionSpaces.Addable, int)

References frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.queue, frodo2.algorithms.odpop.UTILpropagationFullDomain< Val, U, LeafNode< U > >.reportStats, and frodo2.algorithms.AgentInterface< V extends Addable< V > >.STATS_MONITOR.

Referenced by startProcess().

---

The documentation for this class was generated from the following file:

• src/frodo2/algorithms/odpop/UTILpropagation.java
